INPUT IMPEDANCE 22K Ohm MAXIMUM INPUT LEVEL +21dBu (+17dB ref. +4dBu) OUTPUT IMPEDANCE 50 Ohm MAXIMUM OUTPUT LEVEL +20dBu BANDWIDTH <12Hz to 25KHz -1dB CROSSTALK @10kHz Better than -80dB @20kHz Better than -70dB NOISE AT UNITY GAIN reference +4dBu Wideband 22Hz - 22KHz CCIR ARM IEC A Q-Pk CCIR AV -88dB -94dB -95dB -98dB -84dB RMS -86dB -92dB -93dB -96dB - DISTORTION (No Compression and Enhance Off) 100Hz 1KHz 10KHz Unity Gain, +4dBu Input < 0.09% < 0.03% < 0.08% +14dBu Input, 10dB G.R. < 0.15% < 0.15% < 0.15% POWER REQUIREMENTS 115Volt or 230Volt at 50-60Hz, 10 Watts FUSE RATING 50mA for 230Volt, 100mA for 115Volt CONFORMING TO BS EN 60127-2:1991 SHEETIII FUSE TYPE 20mm x 5mm, Class 3 Slo-Blo, 250Volt working CASE SIZE 482mm (w) x 44mm (h) x 200mm (d) WEIGHT (incl packaging) 3.4 Kgs
