INPUT IMPEDANCE 20KOhm MAXIMUM INPUT LEVEL +21dBu (+17dB ref. +4dBu) OUTPUT IMPEDANCE 50 Ohm MAXIMUM OUTPUT LEVEL +20dBu BANDWIDTH <12Hz to 35KHz -1dB CROSSTALK @10kHz Better than -80dB @20kHz Better than -75dB OUTPUT BALANCE Better than 40dB 20Hz to 10kHz INPUT CMR Better than 40dB 20Hz to 10kHz NOISE AT UNITY GAIN reference +4dBu Wideband 22Hz - 22KHz CCIR ARM IEC A Q-Pk CCIR AV -90dB -98dB -99dB -100dB -88dB RMS -89dB -96dB -97dB -98dB - DISTORTION 100Hz 1KHz 10KHz Unity Gain, +4dBu Input < 0.02% < 0.015% < 0.035% +14dBu Input, 10dB G.R. < 0.3% < 0.1% < 0.1% POWER REQUIREMENTS 115Volt or 230Volt at 50-60Hz, 13 Watts FUSE RATING 80mA for 230Volt, 160mA for 115Volt CONFORMING TO BS EN 60127-2:1991 SHEETIII FUSE TYPE 20mm x 5mm, Class 3 Slo-Blo, 250Volt working CASE SIZE 482mm (w) x 44mm (h) x 200mm (d) WEIGHT (incl packaging) 3.4 Kgs
