 16 × stereo or mono audio tracks, or MIDI tracks
5 × selectable SRC (audio) machines | Oneshot Werp Stretch Repitch Grid 5 × selectable FLTR machines: Multi-Mode Lowpass 4 Equalizer Comb Legacy LP/HP 1 × digital base-width filter per track 1 × digital overdrive per track 1 × digital bit reduction 1 × digital sample rate reduction 1 × overdrive master effect 1 × stereo compressor master effect 3 × assignable LFOs per track 400 MB sample memory 20 GB +Drive storage Diverse sample library 4 note polyphony per step 16 × assignable CC controls 2 × assignable LFOs per track 4 × Trig modes Tracks Velocity Retrigs (only works on audio tracks) Preset pool (only works on audio tracks) Keyboard mode with 36 different scales Song Mode 128 steps per pattern and track Individual pattern length per track Individual time scale multiplier per track Parameter locks Trig conditions & trig chance Retrig (audio tracks only) Micro timing 1 × Euclidean sequence generator per track Saturator Delay Supervoid Reverb Panoramic Chorus 128 × 64 pixel OLED screen 2 × ¼” impedance balanced audio out jacks 2 × ¼” impedance balanced audio in jacks 1 × ¼” stereo headphone jack 48 kHz, 24-bit D/A and A/D converters Hi-Speed USB 2.0 port MIDI In/Out/Thru with DIN Sync out Sturdy steel casing Dimensions: W 215 × D 176 × H 63 mm (8.5″ × 6.9″ × 2.5″) (including knobs and feet) Weight: approximately 1.48 kg (3.25 lbs) 100 × 100 mm VESA mounting holes. Use M4 screws with a max length of 7 mm Overbridge enabled Class Compliant USB Audio External Input mixer 3 year Elektron warranty Power Supply PSU-3c Elektron USB cable Exclusive artwork |
Specifications
Audio track features
•
16 × stereo or mono audio tracks, or MIDI tracks
•
5 × selectable SRC (audio) machines: Oneshot Werp Stretch Repitch Grid
•
5 × selectable FLTR machines: M...
