 Reverb, chorus, flanging, modulated delays, mod/verb and delay/verb + Karplus-Strong string synthesis
Three selectable reverb types for a wide variety of ambient textures
Four-octave Karplus-Strong string synthesis mode with damping control for string/ verb full voice capability
LFO section | waveforms to modulate delay time,/reverb size/tone filters, + FILTER section to sculpt high and low EQ of reverb and string section + 4-pole 24dB/octave variable resonance low pass filter HARMONICS section to enhance the reverb's aural spectrum, + adjustable SHIMMER for added +/- 1 octave pitch shifting to the reverb/GLIMMER for dynamic enhancement of harmonics Adjustable reverb core size to increase or decrease space for reflections, allowing pitch control of regenerating reverb INFINITE freezes the input audio prior to the reverb tank Stereo i/o plus extensive CV control of parameters. Independent WET and DRY level controls Ins, Outs, Switches Access to four presets from the front panel USB jack (located on the rear) for performing firmware updates Ultra low noise, high performance 24-bit 96kHz A/D and D/A converters (analog dry path for zero latency dry signal never converted to digital)/ ARM DSP + 32-bit floating point processing provide incredible audio quality. Rack Width: 28hp x Depth: 41mm, 1.61/ Power requirements • +12V rail: 210mA/ -12V rail: 210mA/ +5V rail: 0mA Designed and built in the USA. |
